Name: PRESIDENT LINCOLN II PLUS V4-RICETRASMETTITORE HF/CB AM/FM/SSB 35W ULTIMA VERSIONE
Brand: PRESIDENT
SKU: PRELINCOLNII
Price: 283.00 EUR
Availability: InStock

PRESIDENT LINCOLN II PLUS ULTIMA VERSIONE (V4)

RICETRASMETTITORE PER USO MOBILE HF 10-12 METRI AM/FM/SSB AGGIORNATO CON LE NUOVE FUNZIONI "DIN SIZE" E "VOX BUILT-IN"

(OPERATIVO ANCHE PER LA CB 11 METRI NELLA VERSIONE EXPORT SU RICHIESTA)

- Rotary switch and Up/down channel selector
- VFO Mode
(continuous scanning of 24.890 Mhz to 24.990 Mhz and of 28.000 Mhz to 29.700 Mhz, 27 mhz su richiesta con modifica per export)
- Volume adjustment and ON/OFF
- RF Power
- Manual squelch and ASC
- Multi-functions LCD display
- Frequencies display
- S-meter
- Public Address
- Vox function (Hands free)
- ANL filter, NB and HI-CUT
- RF Gain / Mike gain
- Clarifier
- Channels and memories scan
- 6 Memories
- CTCSS (38 tones)
- DCS (104 codes)
- Dim
- MENU function key
- Beep Function
- Roger Beep
- Mode switch AM/FM/LSB/USB/CW
- Dual watch
- Key locking
- SWR (Power Reading /SWR)
- Preset emergency (EMG 1/2)
- TOT (Time Out Timer) adjustable
- Front microphone plug
- External loudspeaker jack

Back light color:

SPECIFICATIONS

Supply	:	13.2 V
AM	:
FM	:
SSB	:
CW	:
Channel selector	:	rotary, up / down
VFO mode	:
Volume	:	Volume adjustment and ON/OFF
RF Power	:
Squelch	:	Manual squelch
ASC	:
Display	:	LCD multifunction
Frequencies display	:
S-meter	:	Digital
Public address	:
Vox	:
Filter ANL	:
Filter NB	:
Filter HI-CUT	:
RF-Gain	:
Mike-Gain	:
Clarifier	:
Scan	:
Memory	:	6
Dimmer	:
F / Menu function key	:
Key Beep	:
Roger beep	:
Dual watch	:
Key locking	:
SWR (Power Reading /SWR)	:
Preset channel	:	EMG 1/2
CTCSS	:	38 tones
DCS	:	104 codes
Microphone plug	:	front (6 pins)
External Vox microphone jack	:
External loudspeaker jack	:
Size	:	170 (W) x 250 (D) x 52 (H)
DIN Size	:
Weight	:	1,4 kg

TECHNICAL CHARACTERISTICS

General

Modulation modes	:	AM / FM / USB / LSB / CW
Frequency ranges	:	continuous scanning of 24.890 Mhz to 24.990 Mhz and of 28.000 Mhz to 29.700 Mhz
CTCSS	:	38 tones
DCS	:	104 codes
Antenna impedance	:	50 ohms
Power supply	:	12 V
Size	:	170 (W) x 250 (D) x 52 (H)
DIN Size	:
Weight	:	1,4 kg
Accessories supplied	:	power cord with fuse 1 microphone UP/DOWN and its hanger 1 mounting bracket with fixing screws

Transmission

Frequency allowance	:	+/- 300 Hz
Carrier power	:	50 W AM (PEP) / 35 W FM / 35W USB-LSB (PEP) / 12W CW
Transmission interference	:	inferior to - 50 dBc
Audio response	:	300 Hz to 3 KHz in AM/FM/USB/LSB
Emitted power in the adj. channel	:	inferior to 20 ÂµW
Microphone sensitivity	:	3,0 mV
Drain	:	6 A (with modulation)
Modulated signal distortion	:	2 %

Reception

Maxi. sensitivity at 20 dB sinad	:	0.7 ÂµV - 110 dBm (AM) / 0.35 ÂµV - 116 dBm (FM) / 0.28 ÂµV - 118 dBm (USB/LSB/CW)
Frequency response	:	300 Hz to 3 kHz in AM/FM/LSB/USB
Adjacent channel selectivity	:	60 dB
Maximum audio power	:	3 W
Squelch sensitivity	:	minimum 0.2 ÂµV - 120 dBm / maximum 1 mV - 47 dBm
Frequency image rejection rate	:	60 dB
Intermediate frequency rej. rate	:	70 dB
Drain	:	400 mA nominal / 600 mA maximum
